TYPICAL
CHARACTERISTIC:
| Ua |
=
250 V |
| Ug |
=
-8,5 V |
| Ia |
=
10,5 mA |
| S |
=
2,2 mA/V |
| Ri |
=
7,7 kOhm |
| µ |
=
17 |
|
AS
PHASE INVERTER:
|
system
I |
system
II |
| Ub |
=
250 |
350
V |
| Ia |
=
0,7 |
1,0
mA |
| Ia' |
=
0,68 |
0,93
mA |
| Uo/Ug1 |
=
11 |
11 |
| Uo |
=
15 |
24
VRMS |
| dtot |
=
1 |
1
% |
|
LIMITING
VALUES:
| Ua |
=
300 V |
| Wa |
=
2,75 W |
| Ik |
=
20 mA |
| Ug |
=
-50 V |
| Rg |
=
1 MOhm |
| Uk/f |
=
180 V |
| Rk/f |
=
150 kOhm |
|
CAPACITANCES:
|
system
I |
system
II |
| Cg/k |
=
1,9 |
1,9
pF |
| Ca |
=
1,9 |
1,8
pF |
| Cg/a |
=
1,63 pF |
1,63
pF |
|
